Product Description


ModelZZ1167N4617B1
EngineWP10.300E22; 300hp; Euro II
Overall Dimensions(L*W*H)9220×2550×3450mm
Curb weight11860kg
Gross vehicle weight18000kg
Front axle loading capacity16000kg
Rear axle loading capacity7000kg
Approaching angle/ Departure angel19°/18°
Overhang (front/rear)1430mm/2520mm
Wheel base4600mm
Max. Driving speed90km/h
Body Volume14m3
Filler Volume2.2m3
Sewage Tank volume500L
Cycle Time of Filling≤25 s
Lifting Time of Filler8~10 s
Time of Discharging≤45 s
Pressure of Hydraulic system20 Mpa
Hydraulic system control modeElectronic controling system and hydraulic system
