Dimension(L×W ×H)（unloaded）Vehicle length（mm）

10350*2500*3000

Model：

ZZ1257N4647B1R

Cabine：

HW76 (1-Sleeper),  new front face，Air conditioner HW76

Tank volume（m³）

20CBM, Front spraying and back sprinkle，with high-pressure water torch

Approaching angle/Departure angle（°）

16/12

Overhang(front/rear) (mm)

1500/2900

Wheel base (mm)

4600+1350

Max speed（km/h）

75

Curb weight（kg）

12390(Kg)

Loading Weight（kg）

12480(Kg)

Actual loading（kg）

25000

Engine

Model

WP10.340E22

Fuel type

Diesel

Displacement (ml)

Power(kw)

9729

250

Emission

EURO 2

Fuel tanker capacity

400

Transmission

Model

HW19710，10 forward&2 reverse

Brake system

Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating on rear wheels

Steering system

Model

BOSCH （RHD）

Front axle

VGD95 drum, VGD95  Steering with double T-cross section beam

Rear axle

MCX16ZG,Cast axle housing, central double reduction with differential locks between axles and wheels

Tyre:

12.00R20，10PCS+1PCS spare tyre.

12.00R20，10+1

Electrical system

Battery

2X12V/165Ah

Alternator

28V-1500kw

Starter

7.5Kw/24V
